JINK Smart Isolation Drive Ultra Series 30-50W
JINK Smart Isolation Drive Ultra Series 30-50W
픽업 사용 가능 여부를 로드할 수 없습니다.
Overview
The JINK Smart Isolation Drive Lite Series is a cutting-edge solution designed for advanced lighting control and energy efficiency. This series integrates smart technology to provide seamless control over lighting systems, ensuring optimal performance and user convenience. With its compact design and robust features, it is ideal for both residential and commercial applications, offering a reliable and efficient lighting management solution.
Highlights
The JINK Smart Isolation Drive Lite Series integrates Thread connectivity, a low-power, highly reliable wireless protocol, to deliver seamless and efficient lighting control. Designed for both residential and commercial use, it ensures stable performance across large spaces and complex environments. With strong anti-interference capabilities and seamless smart home integration, this series offers a future-proof, user-friendly solution for modern lighting needs.
What’s in the Box
JINK Smart Isolation Drive Ultra Series 30-50W*1
Can access the platform
Tech Specs
| 700mA | 800mA | 900mA | 1000mA | 1100mA | 1200mA | 900mA | 1000mA | ||
| Input | Voltage | 100-265Vac | |||||||
| Frequency | 50/60Hz | ||||||||
| Power | 30w | 32w | 36w | 40w | 45w | 50w | 36w | 40w | |
| Power factor | >0. 96@230Vac | >0. 96@230Vac | >0. 97@230Vac | >0. 97@230Vac | >0. 98@230Vac | >0. 98@230Vac | >0. 97@230Vac | >0. 97@230Vac | |
| Efficiency | 86% | 87% | 87% | 88% | 88% | 88% | 87% | 88% | |
| Standby power consumption | Max. 0.67w | Max. 0.67w | Max. 0.67w | Max. 0.67w | Max. 0.67w | Max. 0.67w | Max. 0.67w | Max. 0.67w | |
| Output | Electric current | 700mA | 800mA | 900mA | 1000mA | 1100mA | 1200mA | 900mA | 1000mA |
| Voltage | 24-38V | ||||||||
| Power | 25.5w | 28w | 31.5w | 35w | 40w | 44w | 31.5w | 35w | |
| Current accuracy | 5% | ||||||||
| Strobe level | No need to flash | ||||||||
| Air-load voltage | Max. 48V | ||||||||
| Power-on time | 0-100%1.5S | ||||||||
| Ripple | 200mv@230VAC | ||||||||
| PWMDimming frequency | 16000Hz | ||||||||
| Function & Protection | Communication mode | Matter Thread | |||||||
| Dimming range | 1-100% | ||||||||
| Voice control | Siri | ||||||||
| Protect | Over-cutting protection, open-circuit protection, over-temperature protection | ||||||||
| Protection level | IP20 | ||||||||
| Environment | Working temperature/humidity | -20-45 C, 20-90%RH | |||||||
| Storage temperature/humidity | -20-80 C, 20-95%RH | ||||||||
| The highest shell temperature | 65°C | ||||||||
| Specifications | Controllable light source | 2700-6500K | |||||||
| Bare plate size | 100*44*19(mm) | ||||||||
| Weight | 118.5g | ||||||||
| Size | 100*47*25(mm) | ||||||||
| Pack | 128g | ||||||||
